9 Causes of Range Shift Inhibited

A healthy gear system can help enhance your ride and enjoy maximum efficiency. That depends on your readiness to give all the necessary attention to the car’s components and warning signs.

The ‘Range shift inhibited’ warning is one of the clear signs that something isn’t right with your Range shifting. What’s it about ‘shift inhibited’? I put up this article to answer that question, but just before that, let me highlight a few things here.

Reluctance to shift gear is another initial symptom of this issue. When it gets to the head, the faulty gearboxes will display the ‘shift inhibited’ warning. Whatever warning you see, action is what you’re required to take. So, let me get to the heart of our discussion.

Range Shift Inhibited: What it Means

“I got a Range Shift Inhibited message, and my vehicle isn’t engaging in gear”. Well, sorry about that. It is a common warning or indicator most vehicle owners experience, especially if you own a Duramax. And you don’t have to worry so much.

The ‘Range Shift Inhibited’ message alerts you that the transmission system of your vehicle is currently unable to shift into different gear ranges.

When this message appears, your vehicle might remain in a particular gear or range for longer than usual. As a result, the vehicle’s performance as well as its ability to speed up or stop will be hampered. As a matter of fact, it is a safety measure to prevent the transmitter from working outside of ideal limits.

Also, it reduces the possibility of further harm to the gearbox or other important parts, while protecting you, the driver. But why does this issue happen? Let’s find out below.

Why is My Vehicle Saying Range Shift Inhibited?

Below are 8 common possible reasons why you’ll see the shifted inhibited message on your dash.

Transmission Control Module (TCM)

The transmission system’s brain is the TCM. Gear shifting may become erratic if the TCM has issues or has trouble communicating. The TCM receives inputs from different onboard systems for proper transmission operation. However, whenever it receives any input beyond or below range, the TCM enters Transmission Abuse Protection Mode.

Afterward, the TCM can begin to prevent shifting into drive and reverse and any or all shifts.

The Neutral Safety Back Up (NSBU)

The NSBU switch sends selector position information directly to your vehicle’s TCM. This switch is susceptible to water contamination, which will in effect allow the switch to give inaccurate readings.

Insufficient Level of Fluid

This alert can be activated by low transmission fluid, which can prevent correct gear shifting. It can be the result of leakage or poor upkeep.

Overheating of the transmission

Mistakes may occur as a result of a lot of heat in the transmission. Heavy loads, hauling, or insufficient cooling can all cause overheating.

Sensor or Electrical Issues

Gear shifting might be hampered by faulty sensors, broken wiring, or electrical issues with the transmission control system.

Mechanical Defects

This alert may be triggered by internal mechanical problems with the transmission, like worn clutch discs, transmission fluid leakage, or broken parts.

Blocked Filter

The movement of fluid through a clogged gearbox filter might obstruct gear shifts.

Defective Solenoids

The transmission’s internal fluid flow is managed by solenoids. Gear shifts may be hindered if they break down or get stuck.

Climatic Conditions

Environmental factors such as rugged terrain or extreme cold can affect transmission, leading to this warning.

How to Fix Range Shift Inhibited Issue

Finding and fixing the underlying issue is usually required to fix the “Range Shift Inhibited” issue in an automatic transmission. We can now fix each of those issues since we are aware of the potential sources of the warning.

I need to add that you need a professional mechanic to get a good job and get over this issue once and for all. You’ll also need to run a perfect maintenance and service culture for your vehicle.

Check the level of fluid

Verify that the level of the transmission fluid is within the acceptable range. If it’s low, top it off with the proper transmission fluid as directed in the owner’s manual of your car.

Ensure cooling system Upkeep

Verify the proper operation of the transmission cooling system. Check and maintain the cooling components as necessary to prevent overheating, which can be a common cause.

Take a diagnostic Scan

Have a professional perform a diagnostic scan to identify any specific fault codes related to the transmission. This can pinpoint electronic or sensor issues.

Do electrical and sensor Checks

Inspect the wiring, connectors, and sensors associated with the transmission. Replace or repair any damaged components.

Replace faulty filter

If the transmission filter is clogged or overdue for replacement, have it changed to ensure proper fluid flow.

Carry out solenoid inspection

Check the transmission solenoids for proper operation. If they are faulty, they may need to be replaced.

Examine the TCM

Check the Transmission Control Module (TCM) for communication and operation issues. It could be essential to replace a module or update the firmware.

Final Thoughts

As we round off, “Range Shift Inhibited” comes as warning about your vehicle’s restricted ability to shift gears. As an automatic transmission issue, shift inhibition is usually due to a recognized problem or malfunction in your car’s components. However, the warning helps to safeguard the transmission and assure the driver’s safety.

Overlooking the warning or making DIY fixes without the required knowledge can result in additional damage. Therefore, it is advised to speak with a skilled mechanic or service expert who can identify the precise cause and suggest the required fixes or maintenance.
