Seeing that AFS light flashing on your Lexus dashboard can be confusing and concerning. If you’re wondering what this warning means and how serious it is, you’re in the right place. I’ll walk you through everything you need to know about your Lexus’s Adaptive Front-lighting System warning light—from what triggers it to how you can fix it yourself.
What Does the Lexus AFS Light Mean?
The AFS (Adaptive Front-lighting System) in your Lexus is a smart headlight system that automatically adjusts your headlight direction based on your driving conditions. When you’re taking a curve at night, the system swivels your headlights to illuminate the road ahead better, making nighttime driving safer and more comfortable.
When you see an “AFS OFF” indicator on your dashboard, it’s telling you something about this system:
| AFS Light Status | What It Means |
|---|---|
| No Light | System is working normally |
| “AFS OFF” solid | System has been manually turned off |
| “AFS OFF” flashing | System has detected a malfunction |
A flashing AFS light is usually accompanied by a “CHECK ADAPTIVE FRONT LIGHTING SYSTEM” message on your multi-information display and indicates your headlights are no longer adjusting automatically.
Common Causes of an AFS Warning Light
Several issues can trigger the AFS warning light in your Lexus, but some are much more common than others:
- Height (level) sensor failure – This is the most frequent cause
- Damaged wiring connections – Particularly to the level sensor
- Steering angle sensor problems
- Headlight swivel motor (actuator) failure
- Water damage to sensors or connections
- AFS control module issues
The vehicle height sensor (also called the level sensor) is usually the main culprit. This sensor monitors your car’s position relative to the road and helps adjust headlight aim. When it fails, your Lexus can’t properly adjust the headlights, triggering the warning.
How to Diagnose an AFS Light Problem
Before spending money at the dealership, try these diagnostic steps:
Check if the System is Just Turned Off
First, look for the AFS button on your dashboard, usually located near your headlight controls or on the left side of your steering wheel. If the AFS is simply turned off, pressing this button should fix the issue immediately.
Inspect the Level Sensor
The height sensor is mounted on the rear suspension of your Lexus. To check it:
- Look under the rear of your vehicle for a small sensor attached to the suspension with a linkage arm
- Check for any visible damage, corrosion, or disconnected linkage
- Look for water intrusion or damaged wiring connectors
Your Lexus has height sensors that monitor suspension movement. If they’re damaged or disconnected, the AFS system can’t function properly.
Scan for Trouble Codes
Using an OBD-II scan tool that can read Lexus-specific codes will pinpoint the exact issue:
| Common AFS Trouble Codes | Meaning |
|---|---|
| B2416 | Height Control Sensor malfunction |
| B2414 | Steering position sensor malfunction |
| B2417/B2418 | Headlight beam level control motor malfunction |
| B2410-B2413 | Swivel actuator communication/motor faults |
| B2420 | AFS ECU malfunction |
A code like B2416 would confirm that the height sensor is indeed the problem.
How to Fix a Flashing AFS Light
Based on the diagnostic results, here’s how to address the common causes:
1. Replacing the Height Sensor
If your diagnostic points to a faulty height sensor, which is the most common cause:
- Locate the height sensor on your rear suspension (typically attached to the control arm)
- Disconnect the electrical connector by pressing the tab and pulling gently
- Remove the mounting bolts holding the sensor in place
- Detach the linkage arm carefully
- Install the new sensor in reverse order
OEM sensors cost between $150-$300, but aftermarket options like Dorman 924-755 can be more affordable while working just as well.
2. Repairing Wiring Issues
If you find damaged wiring:
- Check for corrosion at the connector – clean with electrical contact cleaner
- Repair any broken wires using proper automotive wire and heat-shrink connectors
- Secure loose connections and apply dielectric grease to prevent future corrosion
- Ensure grounds are clean and tight
3. Testing the Sensor Output
You can test if your height sensor is working properly using a multimeter:
- With ignition ON, back-probe the sensor connector
- Check for 5V reference voltage at pin 1
- Verify ground at pin 2
- Measure pin 3 (output) – should vary smoothly between 0.5V-4.5V as suspension moves
- If readings are erratic or outside this range, the sensor needs replacement
Temporary Fixes for the AFS Warning Light
If you need a quick fix until you can properly repair the system:
-
Use the AFS OFF button: Press the AFS OFF button on your dashboard. This will turn off the system and stop the flashing, but your headlights won’t automatically adjust anymore.
-
Remove the AFS fuse: Locate fuse 17 (typically a 7.5A fuse in the driver’s side kick panel) and remove it. This disables the system completely.
Remember that these are temporary solutions only. Neither fix addresses the underlying problem, and driving without proper headlight adjustment could reduce visibility and safety, especially on winding roads at night.
When the Problem Isn’t the Height Sensor
If replacing the height sensor doesn’t solve your AFS light issue:
-
Check the swivel actuators: These small motors that move your headlights can fail. Testing requires removing the headlight assembly.
-
Inspect the steering angle sensor: This sensor tells the AFS system how much you’re turning the steering wheel. It’s located in the steering column and typically requires dealer diagnosis.
-
Test the AFS ECU: Sometimes the control module itself fails. This typically requires dealer-level equipment to diagnose and repair.
Preventing Future AFS Light Problems
Once you’ve fixed your AFS light issue, here’s how to prevent it from coming back:
-
Keep suspension components clean: Spray the height sensors and linkages with silicone lubricant occasionally to prevent corrosion and sticking.
-
Protect electrical connections: Apply dielectric grease to sensor connections when servicing.
-
Address suspension issues promptly: Worn suspension components can stress the height sensor linkage.
-
Check after water exposure: If you’ve driven through deep water, inspect the height sensors for water intrusion.
Understanding Your Lexus AFS System
The AFS system is designed to make night driving safer by providing better visibility around corners. When working properly, it adjusts your headlight beam direction based on:
- Your vehicle’s speed
- Steering angle (how much you’re turning)
- Vehicle pitch (nose-up or nose-down attitude)
This automatic adjustment happens through small electric motors in your headlight assemblies that can swivel the light beam up to 15 degrees in either direction. The system uses input from multiple sensors to calculate the optimal headlight position.
When the AFS warning light comes on, the system enters a fail-safe mode where the headlights remain in a fixed position rather than adjusting dynamically.
The Impact of Aftermarket Modifications
If you’ve modified your Lexus with aftermarket suspension components like lowering springs or coilovers, this can affect the AFS system. The height sensors expect the vehicle to be at factory ride height, and significant changes can cause the system to detect an error condition.
Some owners with modified suspensions choose to permanently disable the AFS system or install height sensor adjustment links to compensate for the new ride height.
The Adaptive Front-lighting System in your Lexus is a valuable safety feature that enhances nighttime visibility. When the warning light appears, it’s usually due to a simple height sensor issue that you can fix with basic tools. By understanding how the system works and following the troubleshooting steps outlined above, you can get your AFS working properly again and enjoy the benefits of this advanced lighting technology.
